Features

Amplifier

# Channels 7.2
Power (8ohms 20-20kHz 0.08%) /Ch 100W
Power (8ohms 20-20kHz 0.05%) /Ch -
THX Certified ✓(Select2 Plus)
Continuous 6ohms Rated
Certified 4ohms performance -
All Discrete Circuitry
3-Stage Inverted Darlington Circuitry
Dual PUSH-PULL Design -
Independent Block Construction (Amp/Preprocessor) -
Toroidal Transformer -
Independent Power Supply -
Bi-amp Capability For Front
BTL Capability For Front -

Processing

DOLBY Decoder True HD, DD Plus, PLIIz
DTS Decoder DTS-HD Master Audio
Dolby PLIIz
ONKYO GAME Surround Modes
DTS Surround Sensation Speaker / Headphone -/-
Neural Surround -
THX Processing Mode
Audyssey Dynamic EQ
Audyssey Dynamic Volume
Direct/Pure Mode ✓/-
Music Optimizer
192K/24 Bit DACs ✓ (Burr-Brown)
VLSC -
isf Certified Calibration Control -

Connectivity

Audio I/O 7 / 2
Phono Input -
Digital Audio IN (OPT/COAX) 2 / 2
Digital Audio OUT (OPT/COAX) -
Composite I/O 5 / 1
S-Video I/O -
Component Video I/O 2 / 1
Front-Panel A/V L / R / V
Front-Panel Optical -
Front-Panel Portable input (stereo mini jack)
HDMI I/O 6 (5+1)/ 1
HDMI Version V1.4a (supports 3D video and Audio Return Channel)
Component Video Upconversion -
Analog To HDMI UpConversion
1080i Upscaling ✓ (DCDi Cinema)
1080p Upscaling ✓ (DCDi Cinema)
Multi-Channel Input -
Analog Pre-Outs Sub
Speaker A/+B -
Powered Zone2
Zone 2 Line Out
Zone 2 Video Out -
Zone 3 Line Out -
U-Port
iPod Ready ✓ (optional UP-A1)
HD Radio Ready ✓ (optional UP-HT1)
XM Radio Ready -
SIRIUS Radio Ready
Internet Radio Capable -
Streaming Audio From PC -
Streaming Audio From USB memory -
PC Input (15 pin D-sub)

Integration Access

RS-232 -
IR Input -
Ethernet -
ONKYO-RI System Control
12V Trigger -

Miscellaneous

Pre-Pro/Learning Remote ✓/-
Back-Lit Remote -
On Screen Remote Programming -
Bi-directional Remote Setup via GUI -
Activity Based Remote -
Color-Coded Speaker Terminals
Auto Speaker Calibration W/Mic. ✓ (Audyssey 2EQ)
OSD Out ✓ (advanced "Home" GUI)
Solid Aluminum Front
Warranty 2 YEARS
